PCBセンサ・オンラインストア > 製品詳細 |
| Performance | ||
|---|---|---|
| Sensitivity (±2.5 %) (Charge Conversion) | 0.5 mV/pC | |
| Overrange | ±8 V | |
| Low Frequency Response (-5 %) | 0.5 Hz | |
| High Frequency Response (-5 %) | 100 kHz | [1] |
| Non-Linearity | ≤1.0 % FS | |
| Environmental | ||
| Temperature Range (Operating) | -54 to +121 °C | |
| Maximum Shock | 49050 m/s² pk | |
| Maximum Vibration (5) | 981 m/s² pk | |
| Electrical | ||
| Excitation Voltage | +18 to 28 VDC | |
| Constant Current Excitation | 2 to 20 mA | |
| Output Voltage | ±5.0 V | |
| Output Impedance | 100 Ohm | |
| Output Bias Voltage | +9 to 13 VDC | |
| Output Polarity | Inverted | |
| Maximum Input Voltage | +30 V | |
| Broadband Electrical Noise (1 to 10000 Hz) | -90 dB | |
| Spectral Noise (1 Hz) | -100 dB | [2] |
| Spectral Noise (10 Hz) | -110 dB | [2] |
| Spectral Noise (100 Hz) | -122 dB | [2] |
| Spectral Noise (1 kHz) | -128 dB | [2] |
| Spectral Noise (10 kHz) | -134 dB | [2] |
| Capacitance (Feedback) | 2000 pF | |
| Overload Recovery Time | 10 µsec | |
| Discharge Time Constant | >1 sec | |
| Resistance (Feedback) | 15000000000 Ohm | |
| Source Capacitance Loading (at input) | -0.0005 %/pF | |
| Physical | ||
| Housing Material | Stainless Steel | |
| Sealing | Epoxy | |
| Electrical Connector (Input) | 10-32 Coaxial Jack | |
| Electrical Connector (Output) | BNC Jack | |
| Size - Diameter | 13 mm | |
| Size - Length | 86 mm | |
| Weight | 32.7 gm | |
| ERC-QC | 校正証明書 |
|---|
