PCBセンサ・オンラインストア > 製品詳細 |
| Performance | ||
|---|---|---|
| Nominal Microphone Diameter | 1/2" | |
| Frequency Response Characteristic (at 0° incidence) | Free-Field | |
| Sensitivity (±1.5 dB) | -38 dB re 1 V/Pa | [2] |
| Sensitivity | 12.6 mV/Pa | [2] |
| Frequency Range (±1 dB) | 5 to 20000 Hz | |
| Frequency Range (±2 dB) | 3.15 to 31500 Hz | |
| Frequency Range (±3 dB) | 3.15 to 40000 Hz | |
| Lower Limiting Frequency (3) | 1.0 to 2.4 Hz | |
| Inherent Noise | 22 dB(A) re 20 µPa | [1] [3] |
| Dynamic Range (3% Distortion Limit) | 150 dB re 20 µPa | [1] |
| Environmental | ||
| Temperature Range (Operating) | -40 to +65 °C | |
| Temperature Coefficient of Sensitivity (+14 to +149°F (-10 to 65°C)) | 0.006 dB/°C | [1] [2] |
| Static Pressure Coefficient | -0.007 dB/kPa | [1] [2] |
| Humidity Coefficient of Sensitivity (0 to 100%, non-condensing) | 0.002 dB/%RH | [1] [2] |
| Influence of Axial Vibration (0.1g (1 m/s²)) | 66 dB re 20 µPa | [1] |
| Electrical | ||
| Polarization Voltage | 0 V | [4] |
| Current Draw | 6.5 mA | [1] |
| Maximum Output Voltage | ±10 Vpk | |
| Output Impedance | <50 Ohm | |
| Physical | ||
| Housing Material | Stainless Alloy | |
| Venting | Rear | |
| Electrical Connector | 3-Pin XLR | |
| Mounting Thread (Grid) | 0.5 - 60 UNS | |
| Size - Diameter (with grid) | 20.1 mm | |
| Size - Height (with grid) | 174.0 mm | |
| Weight | 183.0 gm | [1] |
| 079A49 | |
|---|---|
| 64444-01 | |
| ACS-42 | 校正データ |
