PCBセンサ・オンラインストア > 製品詳細 |
| Performance | ||
|---|---|---|
| Sensitivity (±20 %) | 0.17 pC/(m/s²) | |
| Measurement Range | ±4905 m/s² pk | |
| Frequency Range (+5 %) | 10000 Hz | [3] |
| Frequency Range (+10 %) | 13000 Hz | [3] |
| Resonant Frequency | ≥50 kHz | |
| Non-Linearity | ≤1 % | [1] |
| Transverse Sensitivity | ≤5 % | [2] |
| Environmental | ||
| Overload Limit (Shock) | ±49050 m/s² pk | |
| Temperature Range | -73 to +177 °C | |
| Temperature Range | -73 to +177 °C | |
| Temperature Response | See Graph | [4] |
| Base Strain Sensitivity | ≤1.0 (m/s²)/µε | [4] |
| Electrical | ||
| Capacitance | 310 pF | [4] |
| Insulation Resistance (at 70° F [21°C]) | >10000000000 Ohm | |
| Electrical Isolation (Base) | ≥100000000 Ohm | |
| Physical | ||
| Sensing Element | Ceramic | |
| Sensing Geometry | Shear | |
| Housing Material | Anodized Aluminum | |
| Sealing | Epoxy | |
| Size - Height | 3.6 mm | |
| Size - Length | 11.4 mm | |
| Size - Width | 6.4 mm | |
| Weight | 0.45 gm | [4] |
| Electrical Connector | 3-56 Coaxial Jack | |
| Electrical Connection Position | Side | |
| Mounting | Adhesive | |
