PCBセンサ・オンラインストア > 製品詳細 |
| Performance | ||
|---|---|---|
| Sensitivity (±10 %) | 10.2 mV/(m/s²) | [1] |
| Measurement Range | ±490 m/s² | |
| Frequency Range (±3 dB) | 0.5 to 8000 Hz | [3] |
| Resonant Frequency | 25 kHz | [4] |
| Broadband Resolution | 3434 µm/sec2 | [4] |
| Non-Linearity | ±1 % | [2] |
| Transverse Sensitivity | ≤7 % | |
| Environmental | ||
| Overload Limit (Shock) | 49050 m/s² pk | |
| Temperature Range | -54 to +121 °C | |
| Temperature Response | See Graph %/°F | [4] |
| Enclosure Rating | IP68 | |
| Electrical | ||
| Settling Time (within 1% of bias) | ≤2.0 sec | |
| Discharge Time Constant | ≥0.3 sec | |
| Excitation Voltage | 18 to 28 VDC | |
| Constant Current Excitation | 2 to 20 mA | |
| Output Impedance | <150 Ohm | |
| Output Bias Voltage | 8 to 12 VDC | |
| Spectral Noise (10 Hz) | 78.5 (µm/sec2)/√Hz | [4] |
| Spectral Noise (100 Hz) | 49.1 (µm/sec2)/√Hz | [4] |
| Spectral Noise (1 kHz) | 39.2 (µm/sec2)/√Hz | [4] |
| Electrical Isolation (Case) | >100000000 Ohm | |
| Physical | ||
| Size - Length | 41.9 mm | |
| Size - Width | 18.8 mm | |
| Size - Height | 21.5 mm | |
| Weight | 74.0 gm | |
| Mounting Thread | No Metric Equivalent | [5] |
| Mounting Torque | 2.7 to 6.8 Nm | |
| Sensing Element | Ceramic | |
| Sensing Geometry | Shear | |
| Housing Material | Stainless Steel | |
| Sealing | Welded Hermetic | |
| Electrical Connector | 2-Pin MIL-C-5015 | |
| Electrical Connection Position | Side | |
| 081A97 |
|---|
| M081A97 |
|---|
