PCBセンサ・オンラインストア > 製品詳細 |
| Performance | ||
|---|---|---|
| Sensitivity (±10 %) | .51 pC/(m/s²) | |
| Measurement Range | ±9800 m/s² pk | |
| Frequency Range (±5 %) | 3 kHz | |
| Frequency Range (±1 dB) | 5 kHz | |
| Resonant Frequency | ≥14 kHz | |
| Non-Linearity (per full scale range) | ≤2.5 % | |
| Transverse Sensitivity | ≤5 % | |
| Environmental | ||
| Overload Limit (Shock) | ±19600 m/s² pk | |
| Temperature Range (Operating) | -55 to 649 °C | |
| Temperature Range (Survivable Limit) | -55 to 760 °C | |
| Temperature Range (Cable Termination) | -55 to 482 °C | |
| Temperature Response | See graph | [1] |
| Radiation Exposure Limit (Integrated Neutron Flux) | 1 E10 N/cm² | |
| Radiation Exposure Limit (Integrated Gamma Flux) | 1 E8 rad | |
| Electrical | ||
| Capacitance | 990 pF | [1] [2] |
| Insulation Resistance (@ 1200°F[649°C]) | ≥10 kohm | |
| Insulation Resistance (@ 70° F [21°C]) | ≥100 MOhm | |
| Electrical Isolation | Signal isolated from case | |
| Physical | ||
| Sensing Element | UHT-12™ | |
| Sensing Geometry | Shear | |
| Housing Material | Inconel | |
| Sealing (Sensor Housing) | Hermetic | |
| Sealing (Connector) | Welded Hermetic | |
| Size - Height | 16.7 mm | |
| Size - Length | 29.5 mm | |
| Size - Width | 16.7 mm | |
| Weight (without cable) | 50 gm | [1] |
| Cable Length | 3.05 m | |
| Cable Type | MI Hardline Cable | |
| Cable Termination | 10-32 Coaxial Jack | |
| Mounting | Through Hole | |
| 081C108 | ﾏｳﾝﾄｽｸﾘｭｰ(1/4-28) |
|---|---|
| ACS-1 | 校正データ |
